CHOKES




Capacitor Input
Inductance Maximum Current DC Resistance Weight Dimensions Price per piece
USD
LC-15-150D II 15Hy @ 150mA 200mA 165 2.4kg 80 x 80 x 105 $188
LC-10-200D II 10Hy @ 200mA 260mA 120 2.4kg 80 x 80 x 105 $188
LC-10-250D II 5Hy @ 150mA 330mA 67 2.4kg 80 x 80 x 105 $188
LC-10-350D II 3Hy @ 350mA 450mA 40 2.4kg 80 x 80 x 105 $188
LE-12-150D 12Hy @ 150mA 170mA 180 1.8kg 78 x 72 x 95 $424
LE-8-200D 8Hy @ 200mA 230mA 125 1.8kg 78 x 72 x 95 $424
LE-5-250D 5Hy @ 250mA 330mA 80 1.8kg 78 x 72 x 95 $424
Choke Input
Inductance Current DC Resistance Max AC Dimensions
Weight
Price per piece
USD
LL-20-150D 20Hy @ 150mA 200mA Max
35mA Min
220 700V 85 x 80 x 105
2.4kg
$250
LL-12-200D 12Hy @ 200mA 260mA Max
50mA Min
145 600V 85 x 80 x 105
2.4kg
$250
LL-5-300D 3Hy @ 300mA
350mA Max
100mA Min
55
500V
85 x 80 x 105
2.4kg
$250
Anode Chokes
Pri. Inductance Max Current DC Resistance Weight Dimensions Price per piece
USD
RC-160-15W 160Hy @ 15mA
40Hy @ 30mA
20mA
40mA
116
290
0.8kg 56 x 50 x 80 $160
RC-60-35W 60Hy @ 35mA
15Hy @ 70mA
50mA
100mA
730
183
0.8kg 56 x 50 x 80 $160
RC-10-130W 10Hy @ 130mA
2.5H @ 260mA
150mA
300mA
130
33
0.8kg 56 x 50 x 80 $160
